Q96P3H

96x96mm Multifunction network analyser + THD

Multifunction analyser for use in three-phase three or four-wires systems with unbalanced load and distorted waveforms. In addition to the main parameters of an electrical network (including bi-directional active and reactive energy counting), it has an additional set of "advanced" measurements that allow more efficient monitoring or provide additional information on the operating status of the system. As an option, it can be equipped with a communication interface (Modbus RTU - Ethernet - IEC61850 - PROFIBUS), 2 alarm outputs that can alternatively be programmed as pulse outputs for the retransmission of active and reactive energies, or connection to the Analogue Output modules.
